MINI BALL VALVE (POLISHED) from China manufacturer - Hebei Guanyu Stainless Products Co., Ltd.

Price:	1.15~65.86 USD
Payment Terms:	T/T,L/C,D/P,WU
Place of Origin:	Hebei, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: BTM-1R

Production Capacity: 200000

Delivery Date: 14-45 days

Standard or Nonstandard: Standard

Structure: Ball

Temperature of Media: Medium Temperature

Brand Name: GY

Sizes: 1/4"-4"

Working Medium: Water Oil Gas

Thread Types: NPT BSP BSPT DIN2999

Handle: Lever handle or butterfly h...

Means of Transport: Ocean,Land,Air

Packing: Each in bubble bag, then pa...

Power: Manual

Pressure: Medium Pressure

Material: AISI304 316; CF8 CF8M

Media: Oil

Shape: Reduce Bore

Working Pressure: PN64 1000PSI

Connection: Female Threaded

Option: Locking Device

Certification: ISO9001:2008 CE

Stainless Steel Mini Ball Valve
DN: 6-50mm, Reduce Port
Material:SUS304/316
Pressure:1000PSI / PN64
Medium:water,oil,gas
ISO9001 CE

Stainless Steel Mini Ball Valve

Model: BTM-1R(F/F F/M M/M) Reduce Bore 1000PSI

General Technical Data

Material: SS304,316; CF8, CF8M

Reduce Bore1000PSIWOG

Connector Type: NPT/BSP/BSPT/DIN2999 Thread (F/F F/M M/M)
Port Size: 1/4"-3"

Seat Material: RPTFE

Handle Type: Lever

Operation Type: Manual

Product Features

Made of stainless steel for higher strength and resistance to corrosion

Blow-out proof stem and safe prossure-reducing hole

Lever handle with vinyl sleeve for manual on/off control

Well cast and machining, compact assembly
